Ruijie Reyee RG-AirMetro550G-B, Base Station of RG-AirMetro Series Wireless Bridges

Outdoor PTMP Base Station Specifications Table Specification Details Model RG-AirMetro550G-B Device Architecture External Antenna Base Station (designed for PTP/PTMP links) Radio Infrastructure Dual-radio, 3 spatial streams Spatial Stream Config Radio 1 (2.4 GHz): 1 x 1, SISO (1 spatial stream) Radio 2 (5 GHz): 2 x 2, MIMO (2 spatial streams) Channel Width Support 2.4 GHz: Auto / 20 / 40 MHz 5 GHz: Auto / 20 / 40 / 80 MHz External Antenna Interface Requires external matching antennas (e.g., RG-ANT13-360, RG-ANT16S-120, or RG-ANT20S-90) via RF connectors Physical Dimensions 98.5 mm x 29 mm x 200 mm (3.88″ x 1.14″ x 7.87″) (excluding mounting bracket) Power Over Ethernet 1 x Passive PoE In port Operating Temperature –40°C to 80°C (–40°F to 176°F) Operating Humidity 5% RH to 95% RH (non-condensing) IP Protection Rating IP55 (Outdoor industrial weatherproof grade) Hardware MTBF 400,000 hours (~45 years) Link Diagnostics Integrated Link Bridge Speed Test utility Network Framework Self-Organizing Network (SON) & AI Link Heatmap utility Mobile App Functions Remote device control and service reboots via Ruijie Reyee App SNMP Management SNMPv1, v2c, and v3 Supported SKU: RG-AirMetro550G-B Categories: Airmetro, ISP, Ruijie Reyees Products Loading...Barcode:
